- 規格型號：96781268
- 頻率：20 MHz
- 尺寸：7050mm
- 產品描述：SG-8018CA20.000000MHZ,7050四腳貼片晶振,車規晶振,憑借20MHZ標準頻率,兼容車載中控,儀表盤,車載充電器等多種汽車電子設備規格符合行業通用封裝標準,無需額外調整PCB設計即可快速替換升級,降低研發與生產成本.
SG-8018CA20.000000MHZ,7050四腳貼片晶振,車規晶振
.png)
.png)
SG-8018CA20.000000MHZ,7050四腳貼片晶振,車規晶振
SG-8018CA20.000000MHZ晶振采用高精度石英晶片,經過激光微調工藝確保頻率精度,在-40℃至+125℃寬溫范圍內頻率漂移控制在極小范圍,適配汽車電子對動態環境下頻率穩定性的要求.7050四腳貼片封裝具備良好的散熱性能,可快速傳導工作時產生的微量熱量,避免溫度過高影響性能.此外,產品符合RoHS環保標準,無鉛無鹵素,滿足汽車行業綠色生產要求,適用于新能源汽車電控系統,車載雷達等高端應用場景.
.png)
.png)
SG-8018CA20.000000MHZ,7050四腳貼片晶振,車規晶振
| 原廠型號 Originalmodel： | SG-8018CA 20.000000MHZ | 品牌brand： | EPOSN晶體 |
| Manufacturer品牌 | EPOSN | OperatingTemperature溫度 | -40+105 |
| Series型號 | VT-501 | Current-Supply(Max) | - |
| Type類型 | XO | PackageHeight高度 | 1.2mm |
| Frequency頻率 | 20M | Termination 腳位 | 4-pad |
| 輸出方式 Output： | CMOS | PackageType 封裝類型 | 4-SMD |
| Voltage-Supply電壓 | 1.62-3.63V | Packaging 包裝 | TapeandReel |
| FrequencyStability頻率穩定度 | ±50ppm | 安裝方式 Installation： | Surfacemount |
| Size/Dimension尺寸 | 7050表面貼裝晶振 | 最小包裝數MPQ： | 1000 |
.png)
.png)
SG-8018CA20.000000MHZ,7050四腳貼片晶振,車規晶振
.png)
SG-8018CA20.000000MHZ,7050四腳貼片晶振,車規晶振
| DSC1123CI2-125.0000 | Microchip | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1123CI2-200.0000 | Microchip | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1123AE2-100.0000 | Microchip | DSC1123 | MEMS | 100MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1001CI2-027.0000 | Microchip | DSC1001 | MEMS | 27MHz | CMOS | 1.8 V ~ 3.3 V | ±25ppm |
| DSC1123CE1-156.2500 | Microchip | DSC1123 | MEMS | 156.25MHz | LVDS | 2.25 V ~ 3.6 V | ±50ppm |
| DSC1123CI2-150.0000 | Microchip | DSC1123 | MEMS | 150MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1123CI2-100.0000 | Microchip | DSC1123 | MEMS | 100MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1103DI2-312.5000 | Microchip | DSC1103 | MEMS | 312.5MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1123DI2-050.0000 | Microchip | DSC1123 | MEMS | 50MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1123CI2-156.2500 | Microchip | DSC1123 | MEMS | 156.25MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1123BL2-125.0000 | Microchip | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1123CI5-125.0000 | Microchip | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V | ±10ppm |
| DSC1103CI5-300.0000 | Microchip | DSC1103 | MEMS | 300MHz | LVDS | 2.25 V ~ 3.6 V | ±10ppm |
| DSC1123DL5-200.0000 | Microchip | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V | ±10ppm |
| DSC1123NL5-100.0000 | Microchip | DSC1123 | MEMS | 100MHz | LVDS | 2.25 V ~ 3.6 V | ±10ppm |
| MX574BBD322M265 | Microchip | MX57 | XO (Standard) | 322.265625MHz | HCSL | 2.375 V ~ 3.63 V | ±50ppm |
| DSC1001CI2-018.4320 | Microchip | DSC1001 | MEMS | 18.432MHz | CMOS | 1.8 V ~ 3.3 V | ±25ppm |
| DSC1123CI1-200.0000 | Microchip | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V | ±50ppm |
| DSC1123CI1-156.2500 | Microchip | DSC1123 | MEMS | 156.25MHz | LVDS | 2.25 V ~ 3.6 V | ±50ppm |
| DSC1123AE2-300.0000 | Microchip | DSC1123 | MEMS | 300MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1123AI1-125.0000 | Microchip | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V | ±50ppm |
| DSC1123AI2-125.0000 | Microchip | DSC1123 | MEMS | 125MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1122CE1-125.0000 | Microchip | DSC1122 | MEMS | 125MHz | LVPECL | 2.25 V ~ 3.6 V | ±50ppm |
| DSC1123AE2-200.0000 | Microchip | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1103CI1-075.0000 | Microchip | DSC1103 | MEMS | 75MHz | LVDS | 2.25 V ~ 3.6 V | ±50ppm |
| DSC1123AI2-150.0000 | Microchip | DSC1123 | MEMS | 150MHz | LVDS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1123AI1-200.0000 | Microchip | DSC1123 | MEMS | 200MHz | LVDS | 2.25 V ~ 3.6 V | ±50ppm |
| DSC557-0344SI1 | Microchip | DSC557-03 | MEMS | 100MHz | HCSL | 2.25 V ~ 3.6 V | ±50ppm |
| DSC6003CI1A-033.0000 | Microchip | DSC60XX | MEMS | 33MHz | CMOS | 1.71 V ~ 3.63 V | ±50ppm |
| DSC6111CI1A-008.0000 | Microchip | DSC6100 | MEMS | 8MHz | CMOS | 1.71 V ~ 3.63 V | ±50ppm |
| DSC6011JI1A-024.0000 | Microchip | DSC60XX | MEMS | 24MHz | CMOS | 1.71 V ~ 3.63 V | ±50ppm |
| DSC6083CI2A-032K800 | Microchip | DSC60XX | MEMS | 32.8kHz | CMOS | 1.71 V ~ 3.63 V | ±25ppm |
| DSC6083CI2A-307K000 | Microchip | DSC60XX | MEMS | 307kHz | CMOS | 1.71 V ~ 3.63 V | ±25ppm |
| DSC6001CI2A-004.0000 | Microchip | DSC60XX | MEMS | 4MHz | CMOS | 1.71 V ~ 3.63 V | ±25ppm |
| DSC6001CI2A-032.0000 | Microchip | DSC60XX | MEMS | 32MHz | CMOS | 1.71 V ~ 3.63 V | ±25ppm |
| DSC6083CI2A-250K000 | Microchip | DSC60XX | MEMS | 250kHz | CMOS | 1.71 V ~ 3.63 V | ±25ppm |
| DSC6083CI2A-002K000 | Microchip | DSC60XX | MEMS | 2kHz | CMOS | 1.71 V ~ 3.63 V | ±25ppm |
| DSC6101JI2A-024.0000 | Microchip | DSC6100 | MEMS | 24MHz | CMOS | 1.71 V ~ 3.63 V | ±25ppm |
| DSC1001CC1-047.3333 | Microchip | DSC1001 | MEMS | 47.3333MHz | CMOS | 1.8 V ~ 3.3 V | ±50ppm |
| DSC1030BC1-008.0000 | Microchip | DSC1030 | MEMS | 8MHz | CMOS | 3V | ±50ppm |
| DSC1001BC1-024.0000 | Microchip | DSC1001 | MEMS | 24MHz | CMOS | 1.8 V ~ 3.3 V | ±50ppm |
| DSC1033BC1-026.6000 | Microchip | DSC1033 | MEMS | 26MHz | CMOS | 3.3V | ±50ppm |
| DSC1001DI1-001.8432 | Microchip | DSC1001 | MEMS | 1.8432MHz | CMOS | 1.8 V ~ 3.3 V | ±50ppm |
| DSC1033CI1-048.0000 | Microchip | DSC1033 | MEMS | 48MHz | CMOS | 3.3V | ±50ppm |
| DSC1033CI1-024.0000 | Microchip | DSC1033 | MEMS | 24MHz | CMOS | 3.3V | ±50ppm |
| DSC1033DI1-012.0000 | Microchip | DSC1033 | MEMS | 12MHz | CMOS | 3.3V | ±50ppm |
| DSC1033DI1-036.0000 | Microchip | DSC1033 | MEMS | 36MHz | CMOS | 3.3V | ±50ppm |
| DSC1001CI1-027.0000 | Microchip | DSC1001 | MEMS | 27MHz | CMOS | 1.8 V ~ 3.3 V | ±50ppm |
| DSC1033CI1-050.0000 | Microchip | DSC1033 | MEMS | 50MHz | CMOS | 3.3V | ±50ppm |
| DSC6001CI1A-011.0592 | Microchip | DSC60XX | MEMS | 11.0592MHz | CMOS | 1.71 V ~ 3.63 V | ±50ppm |
| DSC1001CI2-024.0000 | Microchip | DSC1001 | MEMS | 24MHz | CMOS | 1.8 V ~ 3.3 V | ±25ppm |
| DSC1033BE2-024.0000 | Microchip | DSC1033 | MEMS | 24MHz | CMOS | 3.3V | ±25ppm |
| DSC1001DI2-038.4000 | Microchip | DSC1001 | MEMS | 38.4MHz | CMOS | 1.8 V ~ 3.3 V | ±25ppm |
| DSC1001CI5-033.3333 | Microchip | DSC1001 | MEMS | 33.3333MHz | CMOS | 1.8 V ~ 3.3 V | ±10ppm |
| DSC1101DM2-012.0000 | Microchip | DSC1101 | MEMS | 12MHz | CMOS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1001DE5-018.4320 | Microchip | DSC1001 | MEMS | 18.432MHz | CMOS | 1.8 V ~ 3.3 V | ±10ppm |
| DSC1101AI2-040.0000 | Microchip | DSC1101 | MEMS | 40MHz | CMOS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1101AI2-080.0000 | Microchip | DSC1101 | MEMS | 80MHz | CMOS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1101AI2-064.0000 | Microchip | DSC1101 | MEMS | 64MHz | CMOS | 2.25 V ~ 3.6 V | ±25ppm |
| DSC1124CI5-100.0000 | Microchip | DSC1124 | MEMS | 100MHz | HCSL | 2.25 V ~ 3.6 V | ±10ppm |
